Oem titanium cnc machining parts

Product Introduction

Components for High-Performance Applications

Baoji Huacan New Metal Materials Co., Ltd. delivers precision oem titanium cnc machining parts engineered to your exact drawings and specifications. Equipped with more than 40 sets of modern CNC machines and over 10 years expertise in titanium machining, we are capable of over 1,000 tons annually. We specialize in the production of complicated titanium parts with tolerances down to ±0.01mm and surface polishes from Ra 0.4 to 3.2μm. Materials are Grade 2, Grade 5 (Ti-6Al-4V), Grade 7, Grade 9 and Grade 23 and conform to ASTM, AMS and DIN standards. We provide comprehensive OEM/ODM manufacturing services, from prototyping to large volume production.

Product Material Advantages / Product Features/ Product Specification & OEM Customization

Parameter	Details
Material Grades	Grade 2, Grade 5 (Ti-6Al-4V), Grade 7, Grade 9, Grade 23
Material Standards	ASTM, AMS, ASME, DIN
Manufacturing Process	CNC Turning, Milling, Drilling, 5-Axis Machining, Thread Machining
Dimensional Tolerance	±0.01mm (per customer drawings)
Surface Roughness	Ra 0.4–3.2μm
Part Types	Valve Bodies, Connectors, Brackets, Housings, Structural Components
Surface Treatment	Machined Finish, Polishing, Anodizing, Sand Blasting, Pickling
OEM/ODM Service	Yes — drawing-based, 2D/3D model supported
Production Volume	Low to high volume
Design Input	2D drawings, 3D CAD models, sample-based machining

Product Application

Aerospace & Defense: Titanium machined parts include turbine housings, hydraulic manifold blocks and structural brackets. Components must withstand temperature fluctuations from -50°C to 600°C and high-cycle fatigue stresses while lowering aircraft weight.

Medical & Biomedical: Bone plates, spinal cages and dental implants need strict dimensional tolerances and biocompatible surfaces. CNC accuracy permits sophisticated porous shapes that promote osseointegration.

Subsea & Marine: Pressure housings, connecting rings and ROV components are subject to severe hydrostatic pressure and constant seawater contact. Titanium resists crevice corrosion and pitting where stainless steel would fail.

Industrial & Energy: The resilience of oem titanium cnc machining parts to hostile media and extreme temperatures benefit chemical processing equipment, heat exchangers and valve bodies.

Factory Show

Why Choose Our Custom Titanium CNC Machined Components

Titanium is one of the most difficult materials to work with. Its thermal conductivity is poor and hence it concentrates the heat at the cutting edge . This causes more wear to the tool and work hardening . Dimensional precision and surface integrity may quickly be lost without the correct skills.

Our team applies specialized tooling strategies — including high-pressure coolant systems, variable helix end mills, and optimized feed/speed parameters — to overcome these challenges. Every part is produced with structural integrity intact.

You obtain components that combine complicated geometries with the strong mechanical attributes titanium is renowned for: High strength-to-weight ratio, Excellent corrosion resistance and, Outstanding biocompatibility.

Manufacturing Process

Production begins with raw material verification. Certified titanium billets are selected according to ASTM or AMS standards, and chemical composition is confirmed before machining starts.

CNC turning and milling are combined to achieve complex geometries. For intricate features — such as internal channels, threaded interfaces, sealing surfaces, and thin-wall structures — 5-axis CNC machining is applied. This reduces setup time and improves geometric consistency.

Secondary operations including deburring, surface finishing, and assembly are completed before inspection. Each stage is monitored in real time to keep production within tight tolerance windows.

Receiving Drawings

Annealing

Developing Machining Process

Finish Machining

Preparing Raw Materials

Deburring

Rough Machining

Deburring

Manufacturing Capability

Our facility in Baoji — China's Titanium Valley — operates 40+ CNC lathes, machining centers, and gantry systems. Annual precision machining capacity exceeds 1,000 tons.

Upstream capabilities include vacuum arc remelting (VAR) with annual melting capacity over 5,000 tons and forging capacity exceeding 3,000 tons. This integrated supply chain gives you better material traceability and shorter lead times.

melting	melting	forging	forging	rolling

Quality Control

Our multi-stage inspection process covers every production phase:

· Raw material: Spectrometer-based chemical composition analysis and supplier certification checks

· In-process: Real-time dimensional checks at forging, machining, and finishing stages

· CMM inspection: Coordinate measuring machines verify GD&T requirements on finished parts

· NDT: Ultrasonic testing and fluorescent penetrant inspection detect internal and surface flaws

· Mechanical testing: Tensile strength, yield strength, and hardness verified against ASTM/AMS standards

· Surface inspection: Roughness testers and visual checks confirm finish quality

Full documentation — inspection reports, material certificates, and traceability records — ships with every order.

Certifications

Baoji Huacan holds ISO 9001 quality management system certification, covering every stage from raw material intake to final shipment. This ensures consistent process control and product reliability for every batch of the product you order.

Packaging & Shipping

​​​​​​​We provide air freight for urgent orders and sea freight for economical bulk shipments. All shipments come with full paperwork for simple customs clearance.

FAQ

Q: What’s the difference between titanium Grade 2 and Grade 5 titanium?

A: Grade 2 titanium is economically pure titanium with very good corrosion resistance. Used in chemical and marine applications. Grade 5 (Ti-6Al-4V) contains aluminum and vanadium for much greater tensile strength and is the most common grade used for aerospace and structural elements.

Q: Why do titanium parts cost more than steel or aluminum?

A:Titanium needs specific carbide tools, regulated spindle speeds to limit heat buildup and extended cycle times. The wear rates of tools are greater, which increases manufacturing cost – but the performance benefits make the investment worthwhile for demanding applications.

Q: Can you make my parts from my CAD drawings?

A: Yes. We accept 2D drawings and 3D CAD models in common formats. Our engineers will check your files and possibly provide suggestions on design/process improvements before manufacturing.

Q: What kind of surface treatments are available?

A: We can provide natural machined finish, polishing, anodizing (Type 2 and Type 3), sand blasting and pickling. Depending on your practical and esthetic needs, the surface treatment is decided.

Q: What are typical lead times?

A：Prototype runs typically take 2–3 weeks. Production runs generally require 4–6 weeks depending on complexity, volume, and material sourcing.

Contact Us

Ready to source reliable oem titanium cnc machining parts? Send your drawings or requirements to sherry@hc-titanium.com  — our team responds promptly.
